While the factory gearbox assembly procedures may work for basic end users, they are not always enough for the shock loading UTV transaxles and differentials experience in a racing environment. Stock gears can crack and wear prematurely when subjected to extreme off road race conditions, leading to premature drivetrain failure. For this reason, we have developed Weddle Race Prep (WRP) for Polaris, Arctic Cat,  Can-Am, and Speed UTV transaxles and differentials.

Decades of Weddle Industries experience goes into every service. Weddle Industries specializes in the hardest working gearboxes in the world. We put our knowledge and experience into every Weddle Race Prepped UTV gearbox and differential to maximize gear life and ensure each gearbox operates at its highest level.

Learn about complete WRP Transaxles & Diffs

Multi-stage Weddle Race Prep (WRP):

• Total Inspection: All serviced units receive a full magnetic particle inspection (Magna-Flux) on critical internal components, as well as a complete visual inspection prior to any prep or assembly work being performed.
• High Performance Gear Prep: All gears are hand-deburred to remove sharp corners, eliminating areas where cracks start. Gears are then shot-peened to relieve surface tension left over from manufacturing, further deterring crack formation. Finally, all critical internal components are REM Isotropic Superfinished to further reduce imperfections left over from the manufacturing process. REM Superfinishing is applied to all internal components where metal moves against metal in order to reduce friction and temperature.
• Professional Weddle Assembly: All units are re-assembled with new seals, o-rings, and name brand bearings from NTN, SKF, FAG, IKO and other quality brands. All shafts are measured and preload adjusted to minimize deflection caused by heavy shock loading. All fasteners are hand torqued with Loctite. Polaris PRO R WRP receive expert PTL adjustments.

For WRP rates and or more info, call +1 805 562 8600 or email us.

Weddle Race Prep (WRP) is available for the following models:

Arctic Cat
2018-2022 Arctic Cat Wildcat XX
2018-2019 Textron Wildcat XX
2020-2022 Tracker XTR 1000

Polaris
2014+ XP 1000
2016+ XP Turbo
2018+ Turbo S
2018+ RS1
2020+ Pro XP
2022+ Turbo R
2022+ Pro R

Can-Am
2017+ Maverick X3 (All Sub-models)
2022+ Maverick R (DCT)

Speed UTV
2022+ Baja Bandit
2022+ El Jefe
2022+ El Diablo

Questions?  Call +1 805 562 8600 or email us.
